ZAM Steel Coil
Zinc-Aluminum-Magnesium Alloy Coated Steel
Next-generation corrosion resistant steel with self-healing cut-edge protection. 3–5× longer service life than HDG and 1.5–2× better than galvalume in salt spray testing. Ideal for coastal roofing, marine structures, and extreme environments.
What is ZAM Steel?
Zn-Al-Mg — The Next Generation Coated Steel
ZAM steel (Zinc-Aluminum-Magnesium) is a revolutionary corrosion-resistant coated steel product. The coating consists of zinc (Zn) as the base, with carefully controlled additions of aluminum (Al) and magnesium (Mg). This unique alloy composition creates a dense, stable corrosion product layer that provides exceptional protection.
The key innovation: self-healing cut-edge protection. When the coating is scratched or cut, magnesium enables the formation of a protective layer that gradually "heals" exposed edges, preventing red rust from propagating. This makes ZAM the ideal choice for applications where cutting, punching, or drilling is required.
Qiaosi International Trade supplies ZAM coil with coating weights ZAM40 to ZAM275. Available in bare, chromated, oiled, and anti-fingerprint finishes.
Standards: ASTM A792 / JIS G3321 / EN 10346 / GB/T 36022.
Self-Healing Edges
Magnesium enables protective layer at cuts & scratches
3–5× Better than HDG
Superior corrosion resistance in salt spray tests
Coastal Performance
Ideal for marine & high-humidity environments
Heat & UV Reflectivity
High Al content reflects heat, reduces cooling costs
Long Service Life
Exceptional durability in extreme conditions
ZAM vs HDG vs Galvalume
Performance Comparison of Coated Steel Products
2500 Hour Test Results
ZAM Steel
Galvalume Steel
Galvanized Steel
| Property | ZAM (Zn-Al-Mg) | Galvalume (GL) | HDG (GI) |
|---|---|---|---|
| Coating Type | Zn-Al-Mg alloy | 55% Al / 43.5% Zn | > 99% Zn |
| Corrosion Resistance | 3–5× better than HDG | 2–4× better than HDG | Baseline |
| Cut-Edge Protection | ✅ Self-healing | Sacrificial + barrier | Sacrificial only |
| Salt Spray (Bare) | ≥ 1,500 h | ~ 800–1,000 h | ~ 300–500 h |
| Salt Spray (Painted) | ≥ 2,500 h | ~ 1,500–2,000 h | ~ 800–1,200 h |
| Coastal Performance | Excellent | Good | Moderate |
| High-Temp Resistance | Up to 315°C | Up to 315°C | Up to 200°C |
| Formability | Excellent | Good | Good |
Technical Specifications
Full Range of ZAM Product Parameters
📐 Standard Dimensions
| Parameter | Value |
|---|---|
| Coating Type | Zn-Al-Mg Alloy (Zinc-Aluminum-Magnesium) |
| Thickness | 0.18 – 2.0 mm |
| Width | 600 – 1,250 mm |
| Inner Diameter (ID) | 508 mm / 610 mm |
| Coil Weight | 5 – 8 MT (or customized) |
| Standard Length | Coil or sheet (custom lengths) |
⚖️ Coating Weight Range
| Designation | Coating Weight (g/m²) | Typical Use |
|---|---|---|
| ZAM40 | 40 | Light indoor |
| ZAM55 | 55 | General construction |
| ZAM70 | 70 | Roofing / wall cladding |
| ZAM100 | 100 | Industrial / coastal roofing |
| ZAM150 | 150 | Heavy marine environments |
| ZAM200 | 200 | Extreme coastal / offshore |
| ZAM275 | 275 | Maximum protection / marine |
📊 Standards & Equivalents
| Property | Value |
|---|---|
| Standards | ASTM A792 / JIS G3321 / EN 10346 / GB/T 36022 |
| Salt Spray (Bare) | ≥ 1,500 h |
| Salt Spray (Painted) | ≥ 2,500 h |
| Workability | Excellent for roll-forming, bending, stamping |
| Weldability | Compatible with standard welding processes |
Self-healing cut-edge property makes ZAM ideal for punched/slotted profiles and perforated panels.
Mill test certificates (MTC) provided. Third-party inspection welcome at origin.
Applications
Where ZAM Steel Excels — 2 Rows × 4 Columns
Coastal Roofing
Marine-grade roofing & wall systems
Industrial Buildings
Factories, warehouses, port structures
Prefab Houses
Modular & prefabricated construction
Sandwich Panels
Insulated metal panels (PIR / PUR / EPS)
Solar Frames
PV panel mounting & support frames
Agriculture
Sheds, poultry houses, grain storage
Port Structures
Docks, jetties, marine infrastructure
Power Enclosures
Substations, electrical cabinets
Packaging & Shipping
Export-Standard Packaging for Safe Transit — 2 Rows × 3 Columns
General Package
Water-proof Paper & Plastic Film
Steel Strip Outside
Standard Export Package
Shipping via Container
Shipping via Bulk Carrier
Each bundle tagged with: MTC number, coil ID, size, coating weight, net/gross weight.
